Исследование сеточной сходимости сеточно-характеристического метода на химерных сетках в задаче ультразвукового неразрушающего контроля рельсового полотна
- Авторы: Кожемяченко А.А.1,2, Фаворская А.В.1,3
-
Учреждения:
- Московский физико-технический институт
- Научно-исследовательский институт системных исследований РАН
- Научно-исследовательский институт системных исследований Российской академии наук
- Выпуск: Том 63, № 10 (2023)
- Страницы: 1687-1705
- Раздел: МАТЕМАТИЧЕСКАЯ ФИЗИКА
- URL: https://ruspoj.com/0044-4669/article/view/664971
- DOI: https://doi.org/10.31857/S0044466923100071
- EDN: https://elibrary.ru/FOEBUS
- ID: 664971
Цитировать
Аннотация
В работе рассматривается пример решения трехмерной прямой задачи ультразвукового контроля в рельсовом полотне, представляемого в виде линейно-упругой среды, с использованием сеточно-характеристического метода на криволинейной структурированной химерной и регулярных структурированных сетках. Между химерной и регулярными сетками используется взаимная интерполяция, учитывающая особенности перехода от криволинейной к регулярной сеткам в трехмерном пространстве. Предложен аналитический алгоритм для построения химерной сетки. Приведены анализ сходимости разработанных численных алгоритмов в зависимости от изменения шага по пространственным направлениям и сравнительный анализ полноволновых полей модуля скорости распространения возмущения от источника. Библ. 43. Фиг. 17.
