INVESTIGATING POSSIBILITIES OF THERMAL NONDESTRUCTIVE TESTING OF GLASS FIBER REINFORCED PLASTIC SUCKER RODS AND PUMP COMPRESSOR PIPES IN THE OIL INDUSTRY
- Authors: Chulkov A.O.1, Vavilov V.P.1, Makushev O.1, Garaev I.2, Glukhoded A.2, Valovskii K.3
-
Affiliations:
- National Research Tomsk Polytechnic University
- Institute «TatNIPIneft» of PJSC «Tatneft» named after V.D. Shashina
- TATNEFT-Production LLC of PJSC «Tatneft» named after V.D. Shashina
- Issue: No 10 (2025)
- Pages: 44-55
- Section: Thermal methods
- URL: https://ruspoj.com/0130-3082/article/view/692877
- DOI: https://doi.org/10.31857/S0130308225100055
- ID: 692877
Cite item
Open Access
Access granted
Subscription or Fee Access
Abstract
The results of experimental studies on defect detection, such as cracks and impact damages, in glass-reinforced plastic pump compressor pipes (PCP) and glass-reinforced plastic sucker rods (PR) using thermal nondestructive testing method involving ultrasonic and optical stimulation are presented. It is demonstrated that infrared thermographic testing is appropriate for detecting cracks, especially ‘kissing’ ones, whereas traditional thermal inspection based on optical heating is more suitable for identifying delaminations and thinning. The efficiency of the inspection depends on the size of the ultrasonic stimulation zone with sufficient power (approximately 0,8 meters in this study). During optical heating procedures, the testing productivity depends on the size of the heated area and the field of view of the thermal imager and can reach several square meters per hour
About the authors
Arsenii Olegovich Chulkov
National Research Tomsk Polytechnic University
Email: chulkovao@tpu.ru
ORCID iD: 0000-0003-1226-0013
Ведущий научный сотрудник, Центр промышленной томографии, Инженерная школа неразрушающего контроля и безопасности
Russian Federation, 634050 Tomsk, Lenin Avenue, 30Vladimir Platonovich Vavilov
National Research Tomsk Polytechnic University
Email: vavilov@tpu.ru
Russian Federation, 634050 Tomsk, Lenin Avenue, 30
Oleg Makushev
National Research Tomsk Polytechnic University
Email: oam11@tpu.ru
Russian Federation, 634050 Tomsk, Lenin Avenue, 30
Ilmir Garaev
Institute «TatNIPIneft» of PJSC «Tatneft» named after V.D. Shashina
Email: Garaev-Ilmir@tatnipi.ru
Russian Federation, 423403 RT, Almetyevsk, Sovetskaya Street 186A
Alexander Glukhoded
Institute «TatNIPIneft» of PJSC «Tatneft» named after V.D. Shashina
Email: glukhodedav@tatnipi.ru
Russian Federation, 423403 RT, Almetyevsk, Sovetskaya Street 186A
Konstantin Valovskii
TATNEFT-Production LLC of PJSC «Tatneft» named after V.D. Shashina
Author for correspondence.
Email: ValovskiiKV@tatneft.tatar
Russian Federation, 423403 RT, Almetyevsk, Lenin Street, 75
References
- Nikolaev A.V., Gilmanova A.M., Gimazetdinov R.A., Kondratyuk I.I. Fiberglass pump rod // Patent RU 2169250C1. Priority date: 05.11.2000.
- Russkikh G.I. Technology of continuous formation of fiberglass pump rods // PhD dissertation. Polzunov Altai State Technical University. Biysk, 2007. P. 162.
- Malykhina L.V., Mutin I.I., Sakhabutdinov K.G. Experience of using fiberglass pipes at Tatneft // Oil industry. 2009. No. 4. P. 99.
- Gavrilyuk Yu.A., Agafonov A.A., Nazarov D.A., Miller V.K. Experience of using fiberglass tubing at the fields of OAO Udmurtneft // Scientific and technical bulletin of Rosneft. 2014. No. 1 (34). P. 44—47.
- Grachev V.I., Budadin O.N., Fedotov M.Yu., Smotrova S.A., Aniskovich V.A., Kozelskaya S.O., Rykov A.N. Products from composite materials: Non-destructive testing and technical diagnostics. Moscow: Spektr, 2023. P. 336—352.
- Palumbo D., Tamborrino R., Gallietti U., Acersa P., Tati A., Luprano V.A.M. Ultrasonic analysis and lock-in thermography for debonding evaluation of composite adhesive joints // NDT & E International. 2016. V. 78. P. 1—9. doi: 10.1016/j.ndteint.2015.09.001
- Umar M.Z., Vavilov V.P., Abdullah H., Ariffin A.K. Detecting low-energy impact damages in carbon-carbon composites by ultrasonic infrared thermography // Defectoskopiya. 2017. No. 7. P. 62—70.
- Yang Bo, Yaoda Huang, Long Cheng. Defect detection and evaluation of ultrasonic infrared thermography for aerospace CFRP composites // Infrared Physics & Technology. 2013. V. 60. P. 166—173. doi: 10.1016/j.infrared.2013.04.010
- Yunze He, Sheng Chen, Dequiang Zhou. Shared excitation based nonlinear ultrasound and vibro-thermography testing for CFRP barely visible impact damage inspection // IEEE Transactions on Industrial Informatics. 2018. V. 14. P. 1—10. doi: 10.1109/TII.2018.2820816
- Chulkov A.O., Vavilov V.P., Nesteruk D.A., Bedarev A.M., Yarkimbaev Sh., Shagdyrov B.I. Synthesizing Data of Active Infrared Thermography under Optical and Ultrasonic Stimulation of Products Made of Complex-Shaped CFRP // Defectoskopiya. 2020. No. 7. P. 54—60.
- Li Rongcheng, Wang Fei, Yin Peng, Yang Feng, Zhao Jianghao, Yue Zhuoyan, Liu Lixia, Sfarra Stefano, Vesala G.T., Yue Honghao, Liu Junyan. A review of ultrasonic infrared thermography in nondestructive testing and evaluation (NDT & E): Physical principles, theory and data processing // Infrared Physics &Technology. 2025. V. 150. P. 1—20. doi: 10.1016/j.infrared.2025.105961
- https://bzs.ru/catalog/stekloplastikovaya-nasosnaya-shtanga
- Zhou Feng Fu, Sheng Zhang Chao, Qing Xu Min, Cheng Jiang Peng. Identification and Reconstruction of Cracks in Ultrasonic Infrared Thermography // Applied Mechanics and Materials. 2012. V. 249—250. P. 46—50. doi: 10.4028/
