Formation of ultra-smooth highly orientated ZnO films on amorphous surface (SiO2/Si) by magnetron sputtering
- Authors: Ismailov А.М.1, Guidalaeva Т.А.1, Muslimov А.E.2, Grigoriev Y.V.2, Kanevsky V.М.2
-
Affiliations:
- Dagestan State University
- Kurchatov Complex of Crystallography and Photonics, National Research Centre “Kurchatov Institute”
- Issue: No 10 (2024)
- Pages: 9-16
- Section: Articles
- URL: https://ruspoj.com/1028-0960/article/view/664728
- DOI: https://doi.org/10.31857/S1028096024100029
- EDN: https://elibrary.ru/SHQRBK
- ID: 664728
Cite item
Abstract
The influence of temperature of amorphous SiO2/Si substrates on the formation of ultra-smooth highly oriented ZnO(0001) films by direct current magnetron sputtering has been studied. It has been shown that ZnO films obtained at a substrate temperature of 500°С have a lamellar shape of crystallites regardless of the growth rate in the range 1–7 nm/s. This feature of the crystallite morphology is associated with the minimum root-mean-square surface roughness of 0.9 nm for traditional high-speed deposition methods. The ultra-smooth surface of the films and the lamellar shape of the ZnO crystallites are mainly due to the two-dimensional mechanism of film formation under conditions of charging the growing surface in the magnetron discharge plasma.
